2015 John Deere Gator Hpx Hpx 4X4 Diesel Specs, Weight, Horsepower, Price
| Manufacturer | John Deere |
|---|---|
| Model | 2015 John Deere Gator Hpx Hpx 4X4 Diesel |
| Type | Utility UTV |
| Fuel | Diesel |
| Transmission | Continuously Variable |
| Drive | 4X2 or 4X4 |
| Towing | 1600 lbs (725,7 kg) |
| Price | 11269 |
| Years Made | 2015 |
| Recommend Min. Age | 16 |
| Factory | USA |
| Engine Manufacturer | Yanmar |
| Engine Type | Horizontal In-line |
| Cooling System | Liquid cooled |
| Fuel Type | Diesel |
| No of Cylinders | 3 |
| Valve Configuration | OHV |
| Combustion | Carburetor |
| Starter | Electric |
| Displacement | 52.1 cu in (853,8 cc) |
| Engine Stroke | Four Stroke |
| Stroke | 2.91 in (7,4 cm) |
| Bore | 2.76 in (7,0 cm) |
| Horsepower | 18.5 HP (13,8 kW) |
| Torque | 33 ft-lbs (44,7 Nm) |
| Torque RPM | 3350 |
| Fuel Capacity | 5.3 gal (20,1 l) |
| Transmission Type | Continuously Variable |
| Reverse | Yes |
| High-Low Range | Yes |
| Driveline Type | 4X2 or 4X4 |
| Driveline Manufacturer | On-Demand |
| No Of Driveline Modes | 2 |
| Front Brake Type | Dual Hydraulic Disc |
| Rear Brake Type | Dual Hydraulic Disc |
| Front Suspension Type | McPherson Strut Single A-Arm |
| Rear Suspension Type | Independent |
| Steering Type | Rack & Pinion |
| Steering Control | Steering Wheel |
| Wheels Composition | Steel |
| Tread Type | All Purpose |
| Front Tire Diameter | 24 in (61,0 cm) |
| Rear Tire Diameter | 24 in (61,0 cm) |
| Front Tire Width | 9.5 |
| Front Wheel Diameter | 10 |
| Rear Tire Width | 12 |
| Rear Wheel Diameter | 10 |
| Front Tire | 24 x 9.5 – 10 |
| Rear Tire | 24 x 12 – 10 |
| Front Suspension Travel | 5.2 in (13,2 cm) |
| Rear Suspension Travel | 3.5 in (8,9 cm) |
| Rows Total | 1 |
| Rear Shock Qty | 2 |
| Seat Type | Bucket |
| Seat Material | Vinyl |
| No Of Seats | 2 |
| Adjustment Type | Non Adjustable |
| No Of Cupholders | 2 |
| Cargo Bed Material | Steel |
| Light Type | Halogen |
| Fuel Level Warning Type | Gauge |
| Temperature Warning Type | Light |
| Frame | Steel |
| Body Material | Plastic |
| Towing Capacity | 1600 lbs (725,7 kg) |
| Payload Capacity | 1400 lbs (635,0 kg) |
| Bed Capacity | 1000 lbs (453,6 kg) |
| Bed Width | 49 in (124,5 cm) |
| Bed Volume | 11.2 ft3 (0,3 m³) |
| Length | 113,0 in (287,1 cm) |
| Width | 59.3 in (150,6 cm) |
| Front Tread Width | 49.5 in (125,7 cm) |
| Rear Tread Width | 49 in (124,5 cm) |
| Height | 73.5 in (186,7 cm) |
| Platform Height | 12 in (30,5 cm) |
| Wheelbase | 75.2 in (191,0 cm) |
| Ground Clearance | 6 in (15,2 cm) |
| Bed Length | 43.9 in (111,5 cm) |
| Bed Height | 9 in (22,9 cm) |
| Turning Radius | 132,0 in (335,3 cm) |
| Wet Weight | 1473 lbs (668,1 kg) |
| Fuel Injector | No |
| Carburetor | Yes |
| Rear Unlocking Differential | Yes |
| Rear Solid Axle | No |
| Exterior Covers | Standard |
| Brush Guard | Yes |
| Front Bumper | Standard |
| Front Fender Flairs | Standard |
| Rear Fender Flairs | Standard |
| Skid Plate | Standard |
| Front Mud Guards | Yes |
| Rear Mud Guards | Yes |
| Headlight | Standard |
| Headrest | No |
| Grab Rail or Strap | Standard |
| Seat Belts | Standard |
| Rear Hitch | Standard |
| Front Storage Well | Standard |
| Hour Meter | Standard |
| Chain Guard | No |
| Cab Cage | Standard |
| Cab Rollbar | Standard |
| Metallic | No |
| Glove Box / Dash Storage | Standard |
| Power Outlet | Standard |
| Integral Tie-Down Hooks | Yes |
| Overdrive | No |
